Refractory Materials Alumina Fireproof Brick Alumina Hollow Ball Brick

Bubble alumina brick is a kind of light neutral heat preservation refractory material with super high temperature and energy saving. Alumina hollow ball bricks are not only small in body density, but can optimize the structure to reduce the weight of the furnace body, but also have low thermal conductivity, which has a good thermal insulation effect. It is mainly used as the lining of high-temperature industrial kilns below 1800°Cz such as petroleum, chemical, electronics, ceramics, refractory materials and other industries. It plays a pivotal role in various industries.


    Product Feature


    High working temperature :

    It can reach above 1750 degrees, with good thermal stability.

    Optimize the structure and reduce the weight of the furnace body :

    Bubble aluminum bricks are only 1.3-1.5g/cm3. With the same volume of one cubic meter; the use of bubble aluminum bricks can reduce the weight of 1.1-1.7 tons.

    Save materials :

    If bubble aluminum bricks are used, 1.1-1.9 tons of heavy bricks can be saved per cubic meter; and 80% of refractory insulation materials can be saved.

    Energy saving :

    The bubble aluminum brick has obvious heat insulation performance and low thermal conductivity, which can achieve good heat insulation effect, reduce heat dissipation, improve thermal efficiency, and save energy.


    Product Parameter


    Item/Category

    JT-82A

    JT-82B

    (℃)Using temp

    1800

    1750

    (g/cm3) Density

    1.6

    1.3

    (Mpa) Cold crushing strength

    30

    21

    (350℃ W/mk) Thermal Conductivity

    1

    0.75

    Chemical Content

    Al2O3

    99.5

    98

    Fe2O3

    0.1

    0.1

    SiO2

    0.05

    0.1


    Application Area


    ● This product can greatly improve the thermal efficiency of the kiln, shorten the production cycle, reduce the weight of the kiln body, and realize energy saving and consumption reduction. The product can directly contact the flame and is suitable for cracking furnaces, hot blast furnaces, heating furnaces, tunnel kilns, push kilns, crucible furnaces and various electric furnaces and electric kiln linings. It is widely used in metallurgy, refractory materials, light industry, chemical industry, ceramics, Glass, electronics and other industries. The size, physical and chemical indicators, and service life of the product have reached or exceeded the level of similar products at home and abroad.


    11cce4fdb1777adbdcc10ebf7ce7a86

    Iron & Steel

    de98a38234479c235c95f65d8ffe048

    Non-ferrous Metals

    4af2a1ae8eea8e17af04c2fd19f8e5d

    Power Industry

    037c1c9453899893ef84503fc5d4e6e

    Building Materials

    application-9

    Oil Industry

    application-10

    Chemical Industry


    Product Detail



    aebef087462aff57c745d586b0c1fcc
    48b6ead8633446a7f092ad904072f1f
    43d6d5c6db01fce648b0e6e9f8821bf
    f49377a8e8a2178065bb257383dbeb8

    Our Factory


    xiangqingye-1
